What You Get in Your Report

The below are the key sections of our standard Land Sure Residential Stability Report. For more information, book in a call to speak to our technical sales team.

Map location icon representing satellite ground coverage and historical land movement tracking across coordinates and time, including orbit direction.

Site, Coverage & Movement History

Outlines exactly where we’ve assessed (location, coordinates), how far back the data goes (up to 10 years), the number of satellite measurement points used, and the kind of satellite orbits included (ascending/descending).

Stylised ground surface icon with shifting lines, symbolising categorisation of land movement direction and rate—identifying if ground is stable, shifting, or subsiding.

Land Stability Classification & Movement Trends

Breaks down whether the ground is stable, slowly shifting, or moving rapidly - and in what direction.



Classifies movement into clear categories, and identifies if it’s subsiding or uplifting.

Computer monitor icon displaying signal indicators, used to represent data accuracy, RMSE consistency, and reliability scoring for geotechnical reporting.

Data Quality & Reliability

Outlines how precise the measurements are, using indicators like RMSE (error margins), consistency across the site, and signal quality.



Provides a simple reliability rating to show how trustworthy the report’s findings are for decision-making.

More Information on our InSAR Technology

What Our Landslide Monitoring Reports Cover

Our satellite-based InSAR reports provide clear, quantified insights into landslide movement using radar data from satellites like Sentinel‑1 (C-band) and historical platforms (Envisat/ERS). Applying Persistent Scatterer (PS‑InSAR) and Small‑Baseline Subset (SBAS) workflows, each report includes:

  • Time‑series displacement maps showing slope movement over chosen timeframes

  • Velocity trends indicating rate and direction of movement

  • Change-point detection highlighting acceleration or deceleration periods

  • Line-of-Sight (LOS) displacement values, with approximations of vertical/horizontal motion using multi-pass data

  • Overlaid context layers such as terrain, land cover, geology, and rainfall

These deliver a full view of slope behaviour, which are accurate to millimetre levels over months to years.

Technical Key Points

  • Data Sources & Methodology

    • Sentinel‑1 revisits target areas every 12 days (single-satellite scenario); global data is free. Historical imagery from Envisat/ERS stretches back to the early 2000s

    • PS‑InSAR tracks stable reflection points over long periods, while SBAS techniques reduce atmospheric noise and enhance area coverage.

  • Measurement Accuracy

    • Under ideal conditions, we detect vertical movement to within ±2–5 mm/year. Accuracy can reduce on slopes with dense trees or steep terrain.

  • Movement Direction & Velocity

    • Data measures along the satellite’s LOS. Combining ascending and descending passes helps approximate vertical and horizontal components.

  • Temporal Resolution

    • A 12-day revisit enables trend detection over weeks to months. Sudden, rapid slips may not be picked up promptly, but gradual slope movement tends to be reliably captured.

  • Environmental Context

    • Overlays of rainfall, groundwater, and land use support root-cause insights. Field sensors (GNSS, inclinometers) reinforce and validate critical zones.

Legal Disclaimer

Our reports provide displacement data and analysis only.



Here is where Land Sure would stop, and a certified Geotech would start:

  • Supply no geotechnical engineering advice or design

  • Are not licensed geotechnical engineers

  • Do not replace a formal geotechnical engineering report required for regulatory, design or construction purposes

  • Recommend you engage qualified geotechnical professionals for slope stability evaluation, mitigation suggestions, and certification

  • Limit liability to data delivery and reported displacement. We assume no responsibility for field decisions, damages, or costs resulting from report use

  • Expect reports to supplement, not substitute, geological, hydrological, and geotechnical studies in comprehensive risk assessments

Touch Base with our Team

Our InSAR landslide reports give you an "early scout" across vast areas; documenting slope shifts and pointing to hotspots. These reports do not serve as a replacement for certified civil engineer investigations. For homeowners and insurers, these reports offer clear evidence and dated histories of slope movement to support decisions. For engineers and developers, they guide fieldwork, save time, and reduce guesswork.

If you'd like to explore how to fit InSAR reporting into your development, insurance, or engineering workflows—or get a sample NZ landslide report, please order it from our team today.

InSAR Satellite Technology Benefits & Key Advantages

Land Sure is powered by Avant AI - a New Zealand based AI software solutions company. We integrate satellite imagery, IoT sensors and machine learning to create better insights for our clients. We work with governments, councils, civil and property planners to deliver both historical data, as well as ongoing monitoring. We can automate our land stability scans, to connect up with email and text alerts for when land movement starts to accelerate.

Elevated view of a New Zealand residential neighbourhood with hillside homes surrounded by native greenery, showcasing varied rooflines and ongoing construction—representing property development and land use planning in urban NZ environments.

Residential & Property Development

Precise subsidence and uplift measurements are required to design foundations and manage long-term asset value . InSAR provides millimetre-scale time-series displacement maps across large areas, + early identification of subtle ground movements that traditional surveys may miss.

Layering InSAR-derived deformation mapping, enables both a historic look into the land movement over time, but also set up alerts if any part of your section should start to move.

Exportable geo-referenced reports streamline collaboration between geotech teams, architects and project managers, reducing costly surprises during construction

Active New Zealand construction site featuring cranes and excavators working on a large earthworks project, representing civil and infrastructure planning supported by ground stability monitoring.

Civil & Planning

Our Civil and Planning clients use InSAR for real-time infrastructure monitoring, such as bridges, roads and  embankments, as not to disrupt operations.
Early detection of deformation hotspots enhances safety and informs maintenance schedules, extending asset lifespans.


Historical InSAR archives reveal long-term land-stability trends, aiding in hazard zoning and urban growth strategies.

Land Sure’s seamless integration into planning workflows will also accelerate approvals and facilitate transparent and fast communication.

Severely eroded coastal cliff beneath a weathered house in New Zealand, with exposed foundation at risk of collapse—highlighting insurance and legal implications of land subsidence.

Insurance, Legal and Banking

When assessing risk, insurers, legal experts and lenders demand objective, verifiable evidence of ground stability.



Land Sure provides time-stamped InSAR records that support policy under-writing, boundary-dispute resolutions and lending due diligence.



After an event; be it a landslip, earthquake or heavy-rain subsidence, our post-event reporting let you validate claims, allocate liability and manage exposure in days rather than weeks.

Warning triangle inside a house symbol, used to denote potential structural and legal implications of ground movement for insurance or property risk assessments.

Structural, Legal & Insurance RiskS

Provides an evidence-based summary of how the identified ground movement may impact buildings, driveways, utilities, or resale potential.



Flags whether any movement may raise red flags for engineers, banks, insurers, or councils — or require further investigation.

Bar graph with rising trend line icon, visualising long-term land movement data and forward-looking geotechnical risk forecasting.

10-Year Trend Analysis & Future Projections

Shows how the ground has moved over time — including any seasonal patterns, sudden shifts, or ongoing trends.



Projects this data forward to give a rough estimate of what could happen in the next 1–5 years based on past trends.

Clipboard and checkmark icon indicating summarised actions, site recommendations, and guidance for decision-making after ground stability assessment.

Next Steps & Recommendations

Based on the findings, this section offers practical recommendations. This includes whether further geotechnical advice is needed, if monitoring should continue.

This report is not a replacement for a geotechnical engineer, but a tool to support them.

I would like to purchase a Land Sure Report

Fill in your contact information, one of our team will be in touch within 24 business hours.

Expressions of Interest

From as little as $2 per

Land Sure uses InSAR Satellite data, to provide a detailed analysis of land in New Zealand.

We can look back 10 years into the past, to get a more thorough view into the stability of your property or area of interest.

Ideal for: Geotech Engineers, Surveyors + Planners, Insurance and prospective property owners.
Avant Land Sure Ground Stability Report for Whangārei, showing satellite map with surveyed area overlay, a green 75% Ground Stability Safety Score, and summary table of satellite data quality, average ground velocity, and displacement monitoring over 10 years.

Ground Stability Safety Score

Detailed InSAR Satellite Ground Movement Analysis report by Avant, displaying five ground velocity point readings with RMSE accuracy indicators, velocity interpretation key, time-series graphs, and a 10-year displacement trend chart for geotechnical assessment.

Ground Movement Analysis

Avant Critical Subsidence Assessment Report highlighting significant ground movement at a specific site in Whangārei, with red warning banner, 87.27mm total subsidence, -3.74mm/year rate, acceleration pattern analysis, timeline breakdown, and inset velocity time-series chart.

Detailed Subsidence Analysis

Landsure Aotearoa Logo. Dark and Mid Green logo with topographic Map Pin Icon

InSAR Satellite Imaging | Land Movement Analysis

Order Your 10 Year Historical Geodata Report

Land Sure uses InSAR Satellite data, to provide a detailed analysis of land in New Zealand. We can look back 10 years into the past, to get a more thorough view into the stability of your property.

Buy Land Movement Report Data + Ongoing Monitoring & Alerts.

How it Works

Globe Icon.png
Weather Icon.png
Satellite View of Mountainous Residential Housing in Northland New Zealand. The low orbit image shows coastal properties in New Zealand, with a large mountain close by. This image represents all the properties around New Zealand who would really need to get their land movement history checked out, as all of New Zealand moves and Avant (Land Sure) is New Zealand's exclusive leader in providing this technology to New Zealand.

InSAR Satellite Data Analysis

Satellite Icon.png

The Sentinel-1 Satellite, launched by the European Space Agency, has been in low-orbit for the past decade. Every 12 days, this satellite completes a full coverage of the globe.

Local Weather + Geo-Event Data

Weather Icon.png

We connect to multiple weather and geotechnical live datasets via API keys. This data integrates seemlessly to create greater context to your report.

Open-Source Datasets + ML

Globe Icon.png

We connect to open source data from all around the world, to better understand our environment better and refine our Machine Learning prediction models.
